Core Highlights

· Industry Standard Compatibility: DMX channel mapping is fully compatible with Robe MegaPointe profiles for seamless integration into existing shows.

· Advanced Construction: Built with a high-grade Magnesium Alloy housing, offering superior durability and heat dissipation while maintaining a manageable weight for an IP66 fixture.

Light Source & Optics

· Lamp: OSRAM SIRIUS HRI 420W

· Color Temperature: 6450K

· Lamp Life: Approx. 2,000 hours

· Beam Angle: 2° – 44° (Motorized Linear Zoom)

· Focus: Motorized precision linear focus

Color Mixing & Effects

· CMY System: Independent CMY color mixing with linear transition and professional color macros.

· Color Wheel: 13 fixed colors + open, supporting half-colors, linear adjustment, and bidirectional rainbow effects.

· Rotating Gobo Wheel: 9 interchangeable gobos + open, with gobo shake and bidirectional rotation.

· Static Gobo Wheel: 10 fixed gobos + 4 "beam reducers" + open, with gobo shake and bidirectional rotation.

· Prisms: 6 independent rotating prisms; prisms can be overlaid to create diverse combination effects.

· Animation Wheel: 1 bidirectional animation wheel for dynamic water/fire effects.

· Frost: Dual frost filters (Light and Moderate) for soft-edge wash effects.

Movement & Control

· Pan/Tilt: 540° (Pan) / 270° (Tilt) with automatic position correction.

· Strobe: 1-20Hz, supporting pulse, synchronous, and asynchronous strobe effects.

· Dimmer: 0-100% smooth mechanical/electronic dimming.

· DMX Channels: 34 / 39 Channels (Robe MegaPointe compatible).

· Control Modes: DMX-512, RDM, Master-Slave, Auto-run.

· Display: Intuitive LCD display with user-friendly menu navigation.

Power & Physical

· Input Voltage: AC 100-240V, 50/60Hz

· Total Power: 620W

· IP Rating: IP66 (Dust-tight and protected against powerful water jets)

· Material: Lightweight Magnesium Alloy

· Dimensions: 396 x 310 x 735 mm

· Net Weight: 30 kg
