Technical feature

 DMX512/1990 Standard

 12 DMX channels

 Switch output feature: DMX channel value

0-126=OFF, 127-255=ON

 Relay zero-crossing triggering

 LED indicators for each channel

 Over current protected with rapid fuse

 Channel output: 5A per channel

 There are 9 chase program inside and the speed

of each chase can be selected

 DMX input: XLR-D3M

 DMX output: XLR-D3F

 Power supply: AC 88-256V 50/60Hz 0.5A

 Dimension: 482mm×140mm×75mm

 Net Weight: 2.8kg
