Technical feature
DMX512/1990 Standard
12 DMX channels
Switch output feature: DMX channel value
0-126=OFF, 127-255=ON
Relay zero-crossing triggering
LED indicators for each channel
Over current protected with rapid fuse
Channel output: 5A per channel
There are 9 chase program inside and the speed
of each chase can be selected
DMX input: XLR-D3M
DMX output: XLR-D3F
Power supply: AC 88-256V 50/60Hz 0.5A
Dimension: 482mm×140mm×75mm
Net Weight: 2.8kg
