Specification:

Strobe Panel LEDs

LED Type: 1.5W RGB 3in1 LEDs

LED Count: 504 LED Colors: RGB

LED Segments: 14 (2 x 7)

Strobe Tube LEDs

LED Type: 5W 6500K LEDs

LED Count: 280

LED Colors: Cool-White LED Segments: 28 (2 x 14)

Movement

Resolution: 8-16 Bit

Tilt (Degrees): 185°

Control

Control Modes: 8CH / 18CH / 25CH / 95CH / C 8CH /

C 11CH / C 13CH / C 24CH / C 30 CH / C 47CH / C 68CH/

C 74CH / C 97CH

Display: Illuminated graphic LCD Touch Screen

Protocol: USITT DMX-512, RDM, Art-Net, sACN

RDM: Bidirectional communication

Wireless DMX: 2.4 GHz W-DMX™ _(optional)

Cooling: Temperature controlled, overheating protection

Effects

Dimmer: 0-100% electronic

Shutter: electronic, max. 20 Hz

Internal Effects: LED Macro Effects 26

Connectors

Signal connection: Seetronic IP65 XLR 5-Pin or 3-Pin In/Out

Power Input: Seetronic PowerCON TRUE1 In

Art-Net: RJ45 In/Out

Operating Conditions

Mains voltage: 100-240V AC / 50-60Hz Power: 1800W

Maximum ambient temperature: -30°C / 86°F, 50°C / 122°F

Operating Position: any

Mounting Options

Hanging: Omega-Bracket (Support arm side hanging)

Safety wire attachment: foldout eyelets

Folding clamps (optional)

Shipping

Single fixture: cardboard

Tourpack: 4-way Flight Case

Housing Colors

Standard colors: black

Dimensions

Length: 482 mm / 18.9 in

Width: 178 mm / 9.0 in

Height (head horizontal): 243 mm / 9.5 in

Weight

N.W: 13.0 kg G.W: 16.0 kg

Size

56x43x25cm
